Corrugated Pipe Polyurethane Tubing
Polyurethane Corrugated Pipe
Product Characteristic：
◆Oil resistant;flexible low rigidity,glossy surface free of haiogen
phosphor and canmuun.
◆Passed ROHS.
Product Use：
◆Mechanical building,electric equipment,electric control cupboard.
Specifications：
◆Material：Polyurethane
◆Color： Grey（RAL 7037）,Black（RAL 9005）
◆Working temperature range：Min -40℃，Max +90℃，
Short-temp approximately +100℃
◆Flame-resistant degree：HB（UL94），
According to FMVSS 302，Burning celocity < 100mm/min
◆Protection degree：IP68
Datasheet：
|
Item No. |
Standards
|
Metric Measurement |
Bevelling Radius |
Weight |
Length |
|
O.D. |
I.D. |
Stat.R |
Dyn.R |
|
Grey |
Black |
mm |
mm |
mm |
mm |
Kg/m±10% |
M |
|
COR-PU-HB-1/4-G |
COR-PU-HB-1/4-B |
1/4 |
6.5 |
10.0 |
15.0 |
35.0 |
0.014 |
200.0 |
|
COR-PU-HB-5/16-G |
COR-PU-HB-5/16-B |
5/16 |
10.0 |
13.0 |
20.0 |
45.0 |
0.023 |
100.0 |
|
COR-PU-HB-3/8-G |
COR-PU-HB-3/8-B |
3/8 |
12.0 |
15.8 |
25.0 |
55.0 |
0.032 |
100.0 |
|
COR-PU-HB-1/2-G |
COR-PU-HB-1/2-B |
1/2 |
17.0 |
21.2 |
40.0 |
75.0 |
0.048 |
100.0 |
|
COR-PU-HB-3/4-G |
COR-PU-HB-3/4-B |
3/4 |
23.0 |
28.5 |
45.0 |
100.0 |
0.066 |
100.0 |
|
COR-PU-HB-1”-G |
COR-PU-HB-1”-B |
1” |
29.0 |
34.5 |
55.0 |
120.0 |
0.090 |
50.0 |
|
COR-PU-HB-11/4”-G |
COR-PU-HB-11/4”-B |
11/4” |
36.0 |
42.5 |
65.0 |
150.0 |
0.136 |
25.0 |
|
COR-PU-HB-2”-G |
COR-PU-HB-2”-B |
2” |
48.0 |
54.5 |
80.0 |
190.0 |
0.186 |
25.0 |
|
COR-PU-HB-18.5-G |
COR-PU-HB-18.5-B |
18.5 |
14.3 |
18.5 |
35.0 |
65.0 |
0.036 |
100.0 |
|
COR-PU-HB-25.0-G |
COR-PU-HB-25.0-B |
25.0 |
20.0 |
25.0 |
50.0 |
85.0 |
0.056 |
100.0 |
|
COR-PU-HB-32.0-G |
COR-PU-HB-32.0-B |
32.0 |
26.0 |
31.0 |
50.0 |
110.0 |
0.083 |
50.0 |
|
